Automatic 10 Packs/Min 4x6 Package PET / Glass Bottle Wrapping Machine

Categories Bottle Wrapping Machine
Brand Name: BOTTLING MACHINERY
Model Number: FP-150A
Certification: CE/ISO9001-2008
Place of Origin: Zhangjiagang city Jiangsu provice China
MOQ: 1
Price: 8000USD
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10sets per month
Delivery Time: 20-25 working days
Packaging Details: Sea shipping Wooden case
Name: L type Automatic PE film shrink packing machine
Capavity: 10packs per minute
suitable max bottle size: D 25-120mm, H 30-250mm
Max size of film package: 430*305*340mm
thermos shrinkage tunnel temperature: 160 - 200°can adjust at will
Film material: PE、PVC、POF
Dimension: 6150*3300*2100mm
Weight: 1.2Ton
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Automatic 10 Packs/Min 4x6 Package PET / Glass Bottle Wrapping Machine

Description of Automatic 10packs/min 4*6 package PET / glass bottle wrapping machine

1)technical condition and requirement of L type Automatic PE film shrink packing machine:
1,package type:
(1) 350/500/550/600ML big bag:4×6,4×5 ;small bag,3×4,3×5 four type of package.
(2) 1L/1.5L/2L/2.5L big bag:3×3,3×4;small bag,2×2,2×3 four type of package 2, Regarding can, we suggest adopt to package with tray, pack steadily.
3, package speed: 10packs/min
4, meet with filling machine. Speed
(1) 350/500/550/600ML big pack: 4×6, 4×5, (12000-15000b/hr), small pack: 3×5,3×4,(8000-10000b/hr)
(2) 1L/1.5L/2L big pack:3×4, 3×3 (5000-6000b/h), small pack: 2×3, 2×2(3000-4000b/hr)
5, package material:PE thermos shrinkage film width (200-600mm),thickness (0.08-0.12mm)
2)solution of L type Automatic PE film shrink packing machine:
1, according production line, auto arrange, and combine our company FP-150A automatic sealing and cutting mature structure, as the machine fracture.
2, the production line can match with any company filling device. For it stability, the production line main component all adopt to import, joint venture famous brand.
3, if prep-treatment filling machine output is comparatively high, can divide two-way, auto seal and cut at the same time, to meet with output requirement, among FP-150A fracture has original creation, it is the highest-efficiency, highest economical collocate at the same time.
4, PE film adopt to flake, upper and down roll, auto seal and cut to roll type and up to shrinkage efficiency.

3) technical parameter of L type Automatic PE film shrink packing machine:

Facility typeFP-150A type
Facility external size:L6150*W3300*H2100mm
suitable max sizeD 25-120mm, H 30-250mm
Max size of film package430*305*340mm
shrinkage film sizePE,PVC,POF
shrinkage thermos thickness0.03-0.15mm
thermos shrinkage tunnel temperature160 - 200°can adjust at will
max output per minute0-10bag
facility power28KW
Film cutting power4KW
Shrinkage Power20KW
pressure requirement380/220V
facility weight1.2T
fan machine65W 4sets
