Categories | Bottle Wrapping Machine |
---|---|
Brand Name: | BOTTLING MACHINERY |
Model Number: | BZJ-5538+BSE-6040 |
Certification: | CE/ISO9001-2008 |
Place of Origin: | Zhangjiagang city Jiangsu provice China |
MOQ: | 1 |
Price: | 2900-3000USD |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 20sets per month |
Delivery Time: | 20-25 working days |
Packaging Details: | Sea shipping Wooden case |
Name: | Semi-auto shrink wrapping machine |
Application: | Packing bottles in one group |
Capavity: | 0-5packs per minute(4*6 one group is reommeded) |
Automatic Grade: | Semi-Automatic |
PE Film wrapping -cutting unit: | 1100*1100*2050mm 230Kg |
Pack shrink tunnel unit: | 1500*600*400mm 230Kg |
Film type: | PE film |
Powe of tunnel: | 20KW |
This PE film heat shrinking machine is professionally used for shrink packaging of PE materials. It can also be used for high-efficiency shrink packaging of PVC/POF/PP materials. It is suitable for strapping packaging of cans, glass bottles, beer, mineral water and other products.
Technical data of film wrap cut unit:
● Max wrapping size: 350*550*380mm
● Max sealing length: 550mm
● Working air pressure requirement: 0.1m³/min
● Power source: AC220-240V 50/60HZ
● Power: 40W
● Dimension: 1100*1100*2050mm
● Weight: 230kg
Technical data of tunnel unit:
● Tunnel inner size: 1500*600*400mm
● Shrinkage Power source: AC 380 V 3PH
● Shrinkage Power: 20KW
● Blower: 1set 60W
● Conveyor motor: AC 220V /120W
● Conveyor speed: 0-10m/min
● Max loading: 30Kg
● Dimension: 2500*800*1450mm
● Weight: 230kg
The general specification of the whole unit
● Pneumatic component 1set
● Speed adjustment motor 1 set
● Stainless iron wing type heating tube
● Stainless steel convey belt
● Thermos sealing knife cast aluminum heating board has the character as even temperature, long life, is our special product.
● Whole machine outer plastic-sprayed, the frame is made of high-quality carbon steel, main part adopt to stainless steel.
Item | Description | Model | Capacity | Qty |
1.1 | PE Film wrapping-cutting unit | BZJ-5538 | 0-5packs per minute | 1set |
1.2 | Pack Shrink tunnel | BSE-6040 | 1set |
![]() |
