| Categories | Integrating Sphere Spectrophotometer |
|---|---|
| Brand Name: | 3nh |
| Model Number: | YS3060 |
| Certification: | CE / ROHS / TUV / ISO9001:2015 |
| Place of Origin: | P.R.China |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | T/T, L/C, Paypal |
| Supply Ability: | 1000pcs per month |
| Delivery Time: | 3 working days |
| Packaging Details: | Packed in Alumimum box firstly, and then reinforced with carton box for outer packing |
| Display: | 3.5 inch TFT color LCD |
| Measurement: | 48mm integrating sphere |
| Light sources: | Combined LED, UV |
| Observer: | 2° / 10° |
| Wavelength: | 400 - 700nm |
| Wavelength interval: | 10nm |
YS3060 d/8 UV Hunter lab 400 - 700nm wavelength color matching
spectrophotometer
Spectrophotometer with color matching software UV Bluetooth
YS3060 grating spectrophotometer features UV, SCI/SCE, USB /
bluetooth, 8mm / 4mm switch aperture, etc. It has high accuracy
0.03 based on white calibration plate measured 30 times at 5
seconds intervals after white calibration was performed.
Specifications:
| Model Items | YS3060 |
| Optical Geometry | Reflect: di:8°, de:8°(diffused illumination, 8-degree viewing angle) |
| Integrating Sphere Size | 48mm |
| Light Source | Combined LED Light, UV Light |
| Spectrophotometric Mode | Concave Grating |
| Sensor | 256 Image Element Double Array CMOS Image Sensor |
| Wavelength Range | 400-700nm |
| Wavelength Interval | 10nm |
| Semiband Width | 10nm |
| Measured Reflectance Range | 0-200% |
| Measuring Aperture | Dual Aperture: 10mm/8mm & 5mm/4mm |
| Specular Component | SCI&SCE |
| Color Space | CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB |
| Color Difference Formula | ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00v, ΔE(Hunter) |
| Other Colorimetric Index | WI(ASTM E313, CIE/ISO, AATCC, Hunter), |
| YI(ASTM D1925, ASTM 313),TI(ASTM E313, CIE/ISO), | |
| Metamerism Index MI, Staining Fastness, Color Fastness, Color Strength, Opacity, 8° Glossiness | |
| Observer Angle | 2°/10° |
| Illuminant | D65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12 |
| Displayed Data | Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset |
| Measuring Time | 2.6s |
| Repeatability | MAV/SCI: ΔE*≤0.03 |
| Inter-instrument Error | MAV/SCI: ΔE*≤0.15 |
| Measurement Mode | Single Measurement, Average Measurement |
| Locating Method | Camera View Finder Locating |
| Battery | Li-ion battery. 5000 measurements within 8 hours |
| Dimension | L*W*H=184*77*105mm |
| Weight | 600g |
| Illuminant Life Span | 5 years, more than 3 million times measurements |
| Display | 3.5-inch TFT color LCD, Capacitive Touch Screen |
| Data Port | USB, Bluetooth 4.0 |
| Data Storage | Standard 2000 Pcs, Sample 20000 Pcs |
| Language | English, Chinese |
| Operating Environment | 0~40℃, 0~85%RH (no condensing), Altitude < 2000m |
| Storage Environment | -20~50℃, 0~85%RH (no condensing) |
| Standard Accessory | Power Adapter, Built-In Li-ion Battery, User Guide, PC Software, White and Black Calibration Cavity, Dust Cover |
| Optional Accessory | Micro Printer, Powder Test Box |
| ||||||
|
