JMZ-TK-7A Corrosion Resistant Friction Damping Isolator with Up to 95% Isolation Efficiency for Vibration Isolation in Energy & Mining

JMZ-TK Series

JMZ-TK Vibration Isolators: The Invisible Contributor to Enhancing Industrial Equipment Precision and Service Life
In modern manufacturing, processing precision, production efficiency, and equipment service life are core indicators of competitiveness. However, vibration—an often overlooked factor—is silently eroding these indicators. Vibrations from the machine tool itself, the operation of adjacent equipment, and micro-vibrations in the workshop all lead to reduced surface finish of workpieces, accelerated tool wear, and positional accuracy drift. The JMZ-TK series friction damping vibration isolators from Xi'an Hoan are precisely the invisible contributor to solving this pain point.

For high-precision CNC machine tools, coordinate measuring machines (CMMs), lithography machines, and other equipment, the JMZ-TK vibration isolators deliver two core values through their efficient damping characteristics:
1. Enhancing Processing and Measurement Precision
During precision milling, turning, or grinding, relative vibration between the tool and the workpiece directly leaves vibration marks on the workpiece surface, affecting surface quality. The JMZ-TK can quickly dampen internal vibrations generated by spindle rotation and feed system movement, as well as external vibrations transmitted through the foundation, providing an extremely stable platform for the processing process. Similarly, for CMMs, any tiny vibration can cause probe data distortion— the "static zone" established by the JMZ-TK is a prerequisite for ensuring the accuracy of measurement data.

2. Extending Equipment Service Life
Continuous vibration accelerates fatigue wear of key moving components such as machine tool guideways, ball screws, and bearings, leading to loss of precision, increased maintenance costs, and unplanned downtime. By installing JMZ-TK vibration isolators, vibration energy transmitted to the equipment body is isolated and weakened at the source, significantly reducing the dynamic load on each component. This effectively extends the overall service life of the equipment and its precision retention period.

Installation of the JMZ-TK is usually very simple—it can be placed directly between the equipment and the foundation. Its compact design does not significantly alter the original layout of the equipment. Investing in JMZ-TK vibration isolators may seem like an auxiliary cost, but in reality, it is a strategic decision that yields significant long-term returns by improving product yield, reducing waste, lowering maintenance frequency, and extending the equipment lifecycle. It is a wise choice for safeguarding the value of core equipment in modern smart factories.

Structural dimension diagram

Technical Parameter Table

Xi'an Hoan Microwave Co., Ltd. was established in 2005. The company is located in the High-tech Zone of Xi'an. The company covers an area of ​​800 square meters, including 500 square meters of production area and 300 square meters of office area. It is a professional enterprise specializing in the development, production, sales and technical services of military and civilian electronic components, cable assemblies, high-precision electrical connectors, vibration isolators, microwave antennas, waterproof breathable valves and other products.
Our products are widely used in military electronic equipment, aviation communications, postal and telecommunications, civilian electrical appliances, instrumentation and other technical fields. The products are sold all over the country. At present, there are more than 100 military and civilian customers.
Hoan has obtained ISO9001:2005 quality management system certification and military equipment quality management system certification. Since its establishment, the company has strictly organized and implemented operations in accordance with the standard requirements of the quality management system. The product quality is stable and reliable. There have been no customer complaints about quality and leakage accidents, and no production safety accidents.
