Rexroth A6VE Variable Displacement Pump with Compact Flange Mounting High Power Density and Multiple Control Methods for Mobile Appliions

A6VE 28/55/80/107/160/250 Variable Displacement Pumps For Mining Machinery

1, Product introduction
The Rexroth A6VE piston pump is the core power component of heavy-duty hydraulic drive systems, extensive variable control options, and extremely high power density. It can efficiently convert hydraulic energy into mechanical energy and achieve stepless adjustment of output speed and torque to meet various complex working conditions.
2, Working principle and technical characteristics
working principle
The A6VE 28/55/80/107/160/250 piston pump operates based on the inclined disc axial piston principle. The high-pressure oil pushes the plunger to reciproe, and the plunger assembly exerts a force on the inclined plate, driving the output shaft connected to the cylinder body to rotate. By changing the tilt angle of the inclined plate, the displacement and output torque of the motor can be precisely adjusted.
Core product features
· High performance performance: able to withstand high work pressure, wide speed range, and provide strong power.
· Efficient variable control: supports multiple control methods (such as electro-hydraulic proportional ED, hydraulic remote HD, constant power LA, etc.) to achieve precise control.
· Long service life: The heavy-duty bearing design, optimized friction pair, and internal circulation lubriion system ensure long-lasting and stable operation in harsh environments.
· Low noise optimization: Advanced manifold design effectively reduces pressure pulses and operating noise.
· Highly modular: Provides multiple displacement, shaft end, flange, and control options, supporting customized solutions.
3, Detailed explanation of main control methods
Choosing the appropriate control method is the key to selecting A6VE 28/55/80/107/160/250 Variable Displacement Pumps:
· HD control (hydraulic remote control): Control displacement changes through external hydraulic signals.
· ED control (electro-hydraulic proportional control): It is controlled by receiving electrical signals (such as 0-10V) through proportional electromagnets, and is easy to integrate into automation control systems (such as PLC) to achieve precise adjustment.
· LA control (pressure related automatic control/constant power control): automatically adjusts displacement to prevent engine overload, making it an ideal choice for excavators and other equipment.
· DA control (dual control related to speed and pressure): combines pressure and speed sensing functions.
· EZ control (electric control): Controlled by servo motors.
4, Typical appliion areas
The Rexroth A6VE piston pump is widely used in fields that require a wide range of stepless speed regulation and strong driving force:
·Construction machinery: excavator walking drive, rotary drilling rig main winch, concrete pump truck mixing system, crane slewing mechanism.
·Mining machinery: underground loader, mining drilling rig, conveyor belt drive.
·Agricultural machinery: Large combine harvester walking system.
·Marine engineering: deck machinery (winches, anchors), servos.
·Industrial appliions: injection molding machines, metallurgical equipment, test bench drivers.
5, How to choose correctly? Professional Selection Guide
Choosing the correct A6VE piston pump model for your device is crucial. Please consider the following parameters comprehensively:
. System pressure: maximum continuous working pressure and peak pressure.
. Displacement requirement: The maximum and minimum required displacement (unit: ml/r).
. Control mode: Select according to the level of system automation and functional requirements (ED for electronic control, HD for hydraulic control, LA for power protection).
. Installation interface: Confirm the installation flange standards (such as SAE, ISO) and shaft extension form.
. Additional functions: Evaluate whether it is necessary to integrate flushing valves, parking brakes, or oil replenishment pumps.
Contact our professional hydraulic engineers immediately for free technical selection support and official product sample downloads.
6, Frequently Asked Questions (FAQ)
·Q: What is the difference between A6VE motor and A6VM motor?
·A: A6VE is a variable motor, while A6VM is a variable pump. Although structurally similar, their functions are completely different: one is to convert hydraulic energy into mechanical energy (motor), and the other is to convert mechanical energy into hydraulic energy (pump).
·Q: Where can I download the official product samples of A6VE?
·A: Contact us to get it.


Company Information:

QUZHOU OUSTER HYDRAULIC Co., Ltd, founded in 2015 with more than 13 years export experience, specializes in procuring and selling hydraulic pumps and hydraulic pump parts.

Our main products include hydraulic pumps, hydraulic pump parts, hydraulic motors, gearboxes, and hydraulic valves. Our products have been exported to more than 68 countries worldwide.
