4 Color Servo Direct Push Pad Printing Machine
This advanced pad printing machine is specifically engineered for
multi-color helmet printing, accommodating 1-4 color printing
requirements with precision and efficiency.
Product Features
This specialized pad printing series offers comprehensive
multi-color printing capabilities for helmet manufacturing and
other applications. Key features include:
- Choice of oil basin or oil cup ink supply systems
- Touch screen control interface with Chinese & English language
support
- Imported PLC control system for reliable operation
- Independent silicone pad stroke and speed adjustment
- Japan SMC solenoid valves for enhanced durability
- Optional hot air drying system available
- Aluminum alloy die-cast construction with upper/lower and
front/rear cylinders
- Inovance servo motor with three-axis servo control
- 0-360° adjustable rotation angle worktable
- Versatile printing on flat, curved, irregular, and multi-surfaces
Ideal for automotive parts, electronics, appliances, hardware,
plastics, toys, stationery, and various industrial applications.
Construction & Manufacturing Process
Heavy-duty square tube frame ensures structural stability with
painted surface for corrosion resistance and aesthetic appeal.
Machine housing features cast aluminum construction with
CNC-processed, oxidized components for superior durability and
appearance.
Ink Supply Systems
- Oil Basin System: Large printing area, easy installation and removal, flexible
operation - simply pour prepared ink directly into the basin
- Oil Cup System: Environmentally friendly, energy efficient, and aesthetically
pleasing design
Worktable & Servo Motor Capabilities
- Servo-controlled left/right movement with guide rail system
- 0-360° left/right rotation via servo motor
- 360° forward/backward rotation capability
Control System
Mitsubishi PLC control with intuitive touch screen operation
interface for precise machine management.
Technical Specifications
| Parameter | Specification |
|---|
| Output Capacity | 12 pieces/minute |
| Maximum Print/Plate Size | 75×110mm / 100×150mm |
| Power Requirements | AC220V 50-60Hz 1100W |
| Air Pressure | 5-7 bar |
| Dimensions | 115×75×152 cm |
| Weight | 180 kg |
About Hao'an Printing Machinery
Dongguan Hao'an Printing Machinery Co., Ltd., established in 2016,
specializes in automated printing equipment manufacturing. Our
product range includes screen printing machines, transfer printing
machines, stamping machines, and peripheral equipment designed for
various materials and shapes.
Our machinery serves diverse industries including cosmetics, daily
necessities, food, medical supplies, and automotive accessories,
with exports to Europe, United States, South Korea, Middle East,
South Africa, Mexico, and other global markets.
We operate under five core principles: efficiency, excellence,
energy conservation, integrity, and win-win partnerships. Our
professional R&D team creates customized solutions tailored to
specific customer requirements, continuously innovating to enhance
product intelligence and performance.
Beyond equipment supply, we provide comprehensive technical
training and ongoing support services to ensure optimal customer
satisfaction.
Frequently Asked Questions
Q. How long is the machine's warranty period?
A. We offer a 2-year warranty with long-term service support.
Q. What technical support services are provided after purchase?
A. We provide on-site installation services and professional
engineer training.
Q. How will you help us resolve after-sales repair issues if the
machine malfunctions?
A. For machine malfunctions, we provide video support and email
communication, with on-site service available when necessary.
Q. What inks does the machine support?
A. The machine supports UV-based environmentally friendly inks and
imported eco-friendly ink formulations.
Q. What certifications can you provide?
A. We hold ISO9001, SGS, and RoHS certifications for quality and
environmental compliance.
