Product Introduction

CI854BK01 connects AC 800M controllers to PROFIBUS DP/DP-V1 networks. The kit includes the CI854B interface and TP854 baseplate, with line- and master-redundancy support.

Engineering note: Confirm the installed software meets ABB’s minimum: System 800xA 6.0.3.2 or Compact Control Builder 6.0.0-2.

Technical Specifications

Select a category to view its specifications. All categories are closed by default.

Identification & functionView 6 specificationsHide specifications

ABB article number	3BSE069449R1
Package contents	CI854B communication interface + TP854 baseplate
Galvanic isolation	Yes
24 V consumption	Typical 190 mA; older product guide gives 240 mA maximum
Status indicators	Error, run, traffic, primary and dual-mode indications
Pollution degree	Degree 2 to IEC/EN 61131-2

Interface & performanceView 6 specificationsHide specifications

Protocol / role	PROFIBUS DP-V1 master
Channels / ports	2 PROFIBUS channels
Transmission speed	9.6 to 12,000 kbit/s
Services	DP-V0 master class 1 and 2; DP-V1 master class 2 services
Bus capacity	Maximum 32 nodes per segment; up to 124 nodes with repeaters in ABB hardware documentation
Connector	Two female 9-pin DB connectors on TP854

Integration & diagnosticsView 5 specificationsHide specifications

Line redundancy	Yes
Module / master redundancy	Yes
Hot swap	Yes
High Integrity controller use	Yes
Max units on CEX-Bus	12

Power, environment & sizeView 6 specificationsHide specifications

Power dissipation	4.6 W typical
Operating / storage temperature	0 to +55 °C / −40 to +70 °C
Corrosion protection	G3 to ISA 71.04
Protection class	IP20 to EN 60529 / IEC 529
Marine certificates	ABS, BV, DNV-GL, LR
Dimensions / weight	59 × 185 × 127.5 mm; 700 g including base

Compatibility & Replacement

Required software. ABB states compatibility with System 800xA 6.0.3.2, Compact Control Builder 6.0.0-2 and later releases.

Network integration. PROFIBUS DP devices can connect directly. ABB also identifies LD 800P as the linking device for supported PROFIBUS PA connections. The bus must be terminated at its two outermost nodes; powered terminating connectors are required for a working termination.

Confirmed migration relationship. ABB lifecycle documentation identifies CI854BK01 as the replacement for CI854AK01. Treat the exchange as an engineered migration: verify the software baseline, hardware definition and redundancy arrangement before the outage.

Applications & Fault Scenarios

01

Remote I/O and drive networks

Use as the AC 800M PROFIBUS master for supported DP/DP-V1 devices, including distributed I/O and drives.

02

Availability-oriented architectures

Line redundancy uses the two PROFIBUS ports; master redundancy uses two communication interfaces and can be combined with controller/CEX-Bus redundancy where engineered.

03

Loss of a PROFIBUS segment

Check bus termination, connector power, cable continuity and traffic LEDs before replacing the interface.

04

Primary/dual state mismatch

Review primary and dual-mode indicators and the Control Builder configuration. A hardware swap does not correct an inconsistent redundancy definition.

05

Intermittent device dropout

Compare configured baud rate, segment length/topology, repeater use and node count with the commissioned design.

AMIKON SUPPORT

Independent spare-parts support

Amikon can review the part number, installed system, quantity, destination and required date before quotation, helping maintenance teams avoid incomplete purchase requests.

Pre-outage checkpoints

Verify System 800xA/Control Builder release.
Record DP addresses, bus parameters and redundancy settings.
Confirm both outermost terminations are powered and active.
After replacement, check run, traffic, primary and dual indications before returning control.

Amikon Supply & Service

Independent multi-brand support for maintenance, outage and legacy-system requirements.

Amikon warehouse inventory coordination — Organized warehouse handling.

Amikon sales and warehouse team reviewing an order — Sales and warehouse coordination.

Order reviewPart number, quantity, destination and required date checked.

Inspection & testingLabel, condition and serial checks; testing when agreed.

Packing & dispatchProtective export packing and delivery coordination.

DOA, returns & warrantyPrompt issue review under quoted return and warranty terms.

Request for Quotation

Part Number
Quantity
Destination
Required Date
Machine / System Model

Direct RFQ contactMiya ZhengIndustrial automation spare-parts support

Emailsales@amikon.cn

WhatsApp+86 180 2077 6792

Websitedcscontroller.com

Multi-brand Spare Parts Also Requested

WL160-F330 6022771
CXS-A1000-10
EF-A20-A12
787-1662/0106-0000
787-1664
095-902-514-006
PE3MSA00575-6
HB04IJ8DC
3NC2 425-3
P0916JY FBM242
P0916NG
P0960AW
TA-2-81325
ABB FLTR75V05
8G-416-9A
WP 125
67A2510H04
BGS-B-Bo-175-510
1041A-5B171
FW3.5G.8316
5988-040
03-408-608-303
TA-2-81217
J1234
1771-OWNA
FC24020AB
4115-0500
RTF8401
A10530
801-023-07NF6-7SA

These models are listed only as independent sourcing references. They are not substitutes for CI854BK01. Compatibility, configuration and stock must be confirmed separately for each item.

CI854BK01 FAQ

Is ABB CI854BK01 a PROFIBUS master or slave?

It is a PROFIBUS DP-V1 master with two channels.

Can ABB CI854BK01 be used in a redundant configuration?

Yes. ABB confirms line redundancy and module/master redundancy; the engineered project must define the intended arrangement.

Which software versions support ABB CI854BK01?

ABB specifies System 800xA 6.0.3.2, Compact Control Builder 6.0.0-2 and later releases.

Does ABB CI854BK01 replace CI854AK01?

Yes. ABB lifecycle documentation explicitly names it as the replacement. Verify the system software and project hardware definition before migration.

What termination check is required for ABB CI854BK01 networks?

Terminate the two outermost PROFIBUS nodes. ABB notes that terminating connectors must be plugged in and powered.

What should an ABB CI854BK01 RFQ include?

Provide part number, quantity, destination, required date and the AC 800M/System 800xA model and release; include redundancy details if applicable.
