No Power Expansion, Instant Deployment

No Power Expansion, Instant Deployment
No power upgrading or construction required, ready for events and construction sites. Skip complicated power approval and construction to set up temporary charging stations at low cost.
Maxpower EV Charger technical specifications and features
Product Details
Place of Origin:
Luoyang, China
Certification:
CE
Rated Power:
76kW
Capacity:
76kWH
Display Screen:
7-inch Touch Screen
Output Voltage Range:
DC200V-750V(0-100A)
Charging Gun:
GBT/CcS1/CCS2 Optional (7m Cable Length)
Product Size:
1300*710*980mm
Weight:
About 490kg
Protection Level:
IP55
Key Highlights
30kW Rated Power Mobile EV Charger
26kWH Capacity Portable Charging Station
IP55 Protection EV Charger
Technical Specifications
ParameterSpecification
Electric Current250A / 600A
Input Voltage327V - 456Vac
PowerComplete machine (0-2400A), Single circuit (0-25A), Super-charging (0-600A)
Output Voltage50V - 1000V
Waterproof LevelIP54
Input Frequency45Hz - 65Hz
Work Temperature-30°C to 85°C (Derated output when temperature exceeds 50°C)
Power Factor≥ 0.99
Operating Humidity5% - 95% (No frost condensation)
Peak Efficiency≥ 95.5%
Elevation≤ 2000M
Output RoutesMax 12 (Compatible with 6/8/10)
Safety FunctionsShort circuit protection, Leakage protection, Overcurrent protection, Emergency Stop
Material QualityPC Flame retardant
Usage MethodsRFID card / Swipe card / GPRS / RS485 / CAN / Ethernet
Line Length5M / 10M
Network ConnectionOCPP 1.6 protocol
Main Unit Dimensions1355 * 995 * 2000 mm (L * W * H)
Terminal Dimensions325 * 450 * 1430 mm (L * W * H)
PackagingWooden Case
Key Features
  • Dual charging capability with both AC and DC support
  • IP54 rated for dust and water resistance
  • Wide operating temperature range from -30°C to 85°C
  • Multiple authentication methods including RFID and swipe cards
  • Advanced network connectivity with OCPP 1.6 protocol support
  • Comprehensive safety protection systems
  • High efficiency with ≥95.5% peak performance
  • Flexible power configurations for various applications
Flexible Shared Charging Stack
Available in 250A/600A configurations with power options ranging from 480-600-720-800-960kW to meet diverse charging requirements.
