Two Component Epoxy Dispenser Epoxy Resin Potting Machine

YS-D331-AB Performance Characteristics:

1,Stand-alone operation can work without connecting to computer, easy to install and operate.

2,PC or machine touch screen edition,precise positioning and dispensing control.

3,Can accelerate and decelerate in trapezoid and S.

4,Online teaching of dispensing and motor pattern.Can easily complete matrix copy in different path, modify offset,set calibration point and transmit program among several machines,etc.

5,Can restore multipul independent operational procedures.

6,Simple and easy programming, operation and maintaenance.

7,Can be customized at customer's request for different application.

Features:

A glue and B glue mixed automatically according to specified proportion,dispenser then complete the dispensing process. Glue exudation volume and speed can both be controlled.

1, Can quickly draw dots,lines, circles on internal and external surface,vertical plane,gap and spherical surface.

2,Has the functions of programming point,line,arc,circle,irregular figure and supporting 4 axis action.

3,Excellent teaching function. Support array spread,graphic browse and rotate,3D oval and common pictures insert,group edit,etc.

4,2G high speed mini SD file storage, can store 999 dispensing files.

5,Can adjust the angle between dispensing needle and area,to dispense on the internal and external surface of workpiece or L shape vertical space.

6,Can set dispensing volume and thickness, dispensing speed,dispensing time and stopping time.

7,Equipped with specialized controller,stable glue exudation,neat stopping and non drop or leak.

8,Anti-curing function, effectively prevent needle jam out of glue curring.

9,Powerful graphic programming, can import design software such as AutoCAD,CoralDraw and JDpaint to generate different file formats.

Application:

Applicable glue

Silicone, UV glue, AB glue, Epoxy resin, Instant glue, EMI conducting resin, Sealant, Hot glue, Grease, Elargol, Red gum, Solder paste, Thermal grease, Zapon lacquer, Screw fixing agent.

Adantages:

1,Full-automatic dispener can dispense through 3D & 4D path. It can quickly draw dots,line circle and all kinds of irregular figures on the surface,vertical plane,gap and spherical surface.

2,Graphics import or machine screent edit,easy to operate with high precision.

3,Big scale workstation can place multiple products,which is more efficient. Workstation can be customized according to the size of product.

4,Glue dispenser can be equipped with several dispensing heads and operate at the same time, greatly increasing dispensing efficiency.

5,Glue dispenser is applicable for all kinds of glue. Dispensing liquid such as oil paint and printing ink needs to equip additional high- capacity pressure barrel to reduce glue changing time.

6,We are a manufacturer with more than 18 years of production experience. We have excellent R&D and production ability, sound QC system and perfect after-sale service.Robotsung has become a nationwide famous brand in china.

Operating principle

Compress the glue into the feed pipe connected to Piston Chamber by conpressing air into the glue botton(injector). When the piston is in the upstroke, the piston chamber is filled with glue.And When the piston is pushed down, the glue is extruded from the needle nozzle. The dispensing glue amount is decided by the distance of piston downstroke. The gule dispensing amount can be controlled by manual adjustment or by setting the program.

We support Credit Card, paypal,western union.

We support several logistic company as below:

Q1:What is your Warranty for the product? How do you carry out it?

A1:We provide 1 Year Warranty for unit machine and 3 years warranty for main board.

More details pls contact me.

Q2:May I buy samples from you?

A2:Yes! You are welcome to place sample order to test our superior quality and service.

Sample's price is the same as bulk's price.

Q3: What’s the leading time? (How long do you need to prepare my goods?)

A3:1-3 working days for sample orders

3-20 working days for bulk order (based on different quantities).

Q4: How will you deliver my goods to me? How long do I need to wait before my goods arrive?

A4:We offer as many shipping options as possible, such as DHL, UPS, FedEx, TNT ,EMS to enable our customers get their goods rapidly at door. We also ship by economic method such as air cargo and sea cargo, Direct line, Air Mail according to clients' request.

3-7 days for international express, 5-7 days for air cargo, 20-40 days via sea cargo.

Q5: How is your product quality?

A5:We provide supreme - Very rigorous testing process for Incoming Quality Control, Input Process Quality Control, and Final Quality Control for every piece. We follow 20 QC test procedure, and do 100% FQC to ensure your satisfaction.

Q6: Can you put my brand name (logo) on the product?

A6:Yes! We can provide professional OEM services to make it your brand even for your trial sample order.

Q7: How much do I need to pay for your OEM service?

A7: It’s according to your logo's size and color.

Q8: What payment method do you accept?

A5: T/T(Bank transfer), Western Union, Paypal, etc.

Q9: Do you have any After-Sales service?

A9:Yes! We have professional After-sales Dept. follow-up R.M.A.

If you have any technical problem or question with the goods, welcome to contact our Technical Support Dept. or our sales directly.

Q10: Are you just trading company or factory?

A10: We are professional manufacturer for automation machine since 2001.

We can supply the unrivaled Quality and Services with competitive factory price.
