Room-level Air-cooled Precision Cooling For Small Room 13.2kw
| Smart Control Operating System | ||
| Professional Operation | Operation Interface | 4.3-inch true color touchscreen, user-friendly interface, easy to operate |
| Display Content | 1. Real-time operation status of all components 2. Three-level password protection for operation and configuration parameters 3. Automatic maintenance reminders, fault diagnosis, and component alarm information 4. Graphical display of temperature and humidity curves, operation status of all components, and component operation time | |
| Information Recording | 1. Operation time of the entire unit and components 2. 500 historical alarm records 3. All operation actions of the unit | |
| Monitoring Function | Standard support for RS485 communication port, MODBUS-RTU protocol Optional support for Ethernet port, MODBUS-TCP, SNMP, HTTP protocols, and WEB page access to the unit | |
| Control Method | Humidity Control | Optional humidifier, with relative humidity or absolute humidity control |
| Start/Stop Control | Timed start/stop Manual override function | |
| Auto Restart on Power Recovery | Auto restart on power recovery, minimal unit downtime, shortest restart time, prevents damage from prolonged shutdown | |
| Group Control Function | 1. Uses high-reliability CAN bus, supports up to 32 units 2. Four group control modes: load sharing, standby, independent, and distributed 3. Supports load, backup, and layered functions, avoids competitive operation 4. Auto master election: When the master fails, the slave automatically elects a new master 5. Group communication failure maintains normal switch state, temperature and humidity requirements switch to local mode | |
| Safety Protection | Fire Resistance | A-level |
| Panel Protection | IP65 | |
| Insulation Grade | F-level | |
| System Protection | Optional phase sequence protection, over/under voltage protection, water leakage protection, ensures normal operation during unattended conditions | |
| Component Protection | Humidifier heating protection, filter clogging alarm, etc. | |
| Clean Control | Filter Grade | G4 |
|
