| Categories | Self Priming Pump |
|---|---|
| Brand Name: | DENOR |
| Model Number: | DENOR-ZXB |
| Certification: | ISO/CE/TUV |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | 1000—2000 |
| Payment Terms: | T/T |
| Supply Ability: | 30sets/month |
| Delivery Time: | 5-8 work days |
| Packaging Details: | Wooden case packing |
| Name: | Fluorine Lined Chemical Pump |
| Frequency: | Varies depending on model |
| Lift Head: | 82m |
| Impeller Size: | 198mm |
| OEM: | Applicable |
| Pipe Size: | 1 |
| Phase: | Single Phase |
| Rpm: | 2850 |
| Pump Body: | Cast Iron |
| Flow Max: | 46 L/Min |
| Front Cover: | Cast Iron/Aluminum with Brass Insert |
| Driver: | Electric motor or Diesel engine |
| Engine Type: | Diesel |
| Outlet Size: | 2.5inch |
| Maximum Temperature: | Varies depending on model |
| Company Info. |
| Denor Fluid Equipment (wuhan) Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
FZB Fluoroplastic Self-priming Pump
Fluorine-Lined Self-Priming Pumps
Fluorine-lined self-priming pumps are specialized equipment designed for the efficient transfer of highly corrosive and aggressive fluids. These pumps feature a unique lining made from fluoropolymers, which provides exceptional chemical resistance and protects the pump components from degradation. The self-priming capability allows these pumps to draw fluid from a lower level without requiring manual priming, making them ideal for applications where fluid levels fluctuate.
These pumps are commonly used in industries such as chemical processing, pharmaceuticals, and wastewater treatment, where safety and reliability are paramount. Their robust design ensures long-lasting performance, while the fluorine lining minimizes maintenance needs and extends the service life of the pump. With their ability to handle a wide range of fluids, including acids, alkalis, and solvents, fluorine-lined self-priming pumps are an excellent choice for demanding applications.
Performance Data Sheet
| Type | Flow m³/h | Head m | self-priningtime(s) | Inlet*Outlet mm | Power kw | NPSHr m | Speed r/min |
| FZB 25-20 | 1.5 | 19 | 180 | 25X25 | 2.2 | 3 | 2900 |
| 3.6 | 18 | ||||||
| 6 | 16 | ||||||
| FZB 40-20 | 5 | 22 | 180 | 40X50 | 3 | 3 | 2900 |
| 8 | 20 | ||||||
| 12 | 17 | ||||||
| FZB 40-30 | 5 | 32 | 150 | 40X50 | 4 | 3.5 | 2900 |
| 8 | 30 | ||||||
| 12 | 28 | ||||||
| FZB 50-20 | 8 | 22 | 180 | 50X50 | 3 | 3 | 2900 |
| 12 | 20 | ||||||
| 15 | 17 | ||||||
| FZB 50-30 | 8 | 22 | 150 | 50X50 | 4 | 3.5 | 2900 |
| 12 | 30 | ||||||
| 15 | 28 | ||||||
| FZB 50-45 | 8 | 47 | 150 | 50X40 | 7.5 | 3.5 | 2900 |
| 12 | 45 | ||||||
| 15 | 43 | ||||||
| FZB 50-70 | 8 | 72 | 150 | 50X32 | 15 | 4 | 2900 |
| 12 | 70 | ||||||
| 15 | 65 | ||||||
| FZB 65-20 | 15 | 22 | 200 | 65X50 | 5.5 | 4 | 2900 |
| 25 | 20 | ||||||
| 35 | 17 | ||||||
| FZB 65-30 | 15 | 32 | 200 | 65X50 | 7.5 | 4 | 2900 |
| 25 | 30 | ||||||
| 35 | 27 | ||||||
| FZB 65-45 | 15 | 47 | 180 | 65X40 | 11 | 4 | 2900 |
| 25 | 45 | ||||||
| 35 | 38 | ||||||
| FZB 65-70 | 15 | 72 | 180 | 65X40 | 30 | 4 | 2900 |
| 25 | 70 | ||||||
| 35 | 65 | ||||||
| FZB 80-20 | 35 | 22 | 150 | 80X65 | 7.5 | 4.5 | 2900 |
| 50 | 20 | ||||||
| 60 | 17 | ||||||
| FZB 80-30 | 35 | 32 | 150 | 80X65 | 11 | 4.5 | 2900 |
| 50 | 30 | ||||||
| 60 | 35 | ||||||
| FZB 80-45 | 35 | 47 | 180 | 80X65 | 15 | 4.5 | 2900 |
| 50 | 45 | ||||||
| 60 | 42 | ||||||
| FZB 80-70 | 35 | 72 | 200 | 80X50 | 30 | 5 | 2900 |
| 50 | 70 | ||||||
| 60 | 65 | ||||||
| FZB 100-30 | 65 | 32 | 150 | 100X80 | 18.5 | 6 | 2900 |
| 100 | 30 | ||||||
| 110 | 26 | ||||||
| FZB 100-45 | 65 | 46 | 150 | 100X80 | 30 | 6 | 2900 |
| 100 | 45 | ||||||
| 110 | 40 |
|
