| Brand Name: | RUIJIA |
| Model Number: | RJDW-005 |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1 |
| Price: | USD534 ~616/piece |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 Piece/Pieces per Month |
| Delivery Time: | Within 2Weeks |
| Packaging Details: | Standard export packaging |
| Description: | Static torque sensor |
| Operating temperature: | -20-80℃ |
| Output type: | Analog signal |
| Precision: | 0.05% |
| Applicable scenarios: | installation engineering |
| Output: | 5-15V |
| Company Info. |
| Xian Ruijia Measurement Instruments Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
1. Static torque sensor
2. Compact structure, easy to install
3. Protection grade: IP65;
4. Used for static , non-continuous rotation torque measurement.
| Range | 1, 2, 3, 5, 6, 10, 20, 30, 50, 100, 150N.M |
| Comprehensive error | ≤±0.1%, ±0.3% |
| Sensitivity | 1.5±10%mV/V |
| Zero balance | ±2.0%F.S |
| Non-linearity | 0.1, 0.3%F.S |
| Hysteresis | ≤±0.05%F.S |
| Repeatability | ≤±0.05%F.S |
| Creep | ≤±0.03%F.S/30min |
| Temp.effect on span | ±0.05%F.S/10℃ |
| Temp.effect on zero | ±0.05%F.S/10℃ |
| Input resistance | 410±20Ω |
| Output resistance | 350±10Ω |
| Insulation resistance | ≥5000MΩ/100VDC |
| Excitation voltage | 9~15VDC |
| Compensated temp range | -10~60℃ |
| Operating temp Range | -20~80℃ |
| Safe overload | 120%F.S |
| Ultimate overload | 150%F.S |
| Electrical connections | RED/E+, BLACK/E- GREEN/S+, WHITE/S- |










|
