IFM Position sensors Inductive sensors Sensors with long sensing range IM0011 40 x 40 x 120

IFM Position sensors Inductive sensors Sensors with long sensing range IM0011 40 x 40 x 120

IFM Position sensors Inductive sensors Sensors with long sensing range IM0011 40 x 40 x 120
IFM Position sensors Inductive sensors Sensors with long sensing range IM0011 40 x 40 x 120
Categories IFM Pressure Sensor
Brand Name: IFM
Model Number: IM0011
Place of Origin: Germany
MOQ: 1pc
Price: $60-$150
Payment Terms: T/T, L/C
Supply Ability: 30pcs/month
Delivery Time: 3-5days
Packaging Details: new in box
Warranty: 1year
Output function: normally open / closed; (selectable)
Sensing range [mm: 9
Output function normally open / closed; (selectable) Sensing range [mm: 9
Dimensions [mm: 9
Operating voltage [V: 9
Protection class: II
Protection: IP 65
Contact Now
Company Info.
Xiamen ZhiCheng Automation Technology Co., Ltd
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

IFM Position sensors Inductive sensors Sensors with long sensing range IM0011 40 x 40 x 120

Output functionnormally open / closed; (selectable)
Sensing range [mm]15
Housingrectangular
Dimensions [mm]40 x 40 x 120
Electrical data
Operating voltage [V]20...250 AC/DC
Protection classII
Reverse polarity protectionno
Outputs
Output functionnormally open / closed; (selectable)
Max. voltage drop switching output DC [V]6
Max. voltage drop switching output AC [V]6.5
Minimum load current [mA]5
Max. leakage current [mA]2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC)
Permanent current rating of switching output AC [mA]250; (350 (...50 °C))
Permanent current rating of switching output DC [mA]100
Short-time current rating of switching output [mA]2200; (20 ms / 0,5 Hz)
Switching frequency AC [Hz]20
Switching frequency DC [Hz]55
Short-circuit proofno
Overload protectionno
Monitoring range
Sensing range [mm]15
Real sensing range Sr [mm]15 ± 10 %
Operating distance [mm]0...12.1
Accuracy / deviations
Correction factorsteel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2
Hysteresis [% of Sr]1...15
Switch-point drift [% of Sr]-10...10
Operating conditions
Ambient temperature [°C]-25...80
ProtectionIP 65
Tests / approvals
EMC
EN 60947-5-2
EN 55011class B
MTTF [years]603
UL approval
Ta0...40 °C
Enclosure typeType 1
voltage supplyHazardous voltage
File number ULE174191
Mechanical data
Weight [g]188.5
Housingrectangular
Mountingflush mountable
Dimensions [mm]40 x 40 x 120
MaterialPPE
Displays / operating elements
Display
Switching status1 x LED, yellow
Electrical connection
Required protectionminiature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting
Remarks
Remarks
Recommendation: check the unit for reliable function after a short circuit.
5 positions of the active zone possible
Pack quantity1 pcs.
Electrical connection
Connectionterminals: ...2.5 mm²; Cable sheath: Ø 7...13 mm; Cable gland: M20 X 1.5
