| Categories | TOYOTA GPS Navigation |
|---|---|
| Brand Name: | OEM|ASTRAL |
| Model Number: | AST-9220 |
| Certification: | CE, ROHS, FCC |
| Place of Origin: | CHINA |
| MOQ: | 1 piece |
| Price: | 230-280USD |
| Payment Terms: | L/C, T/T, Western Union, PayPal |
| Supply Ability: | 10,000 pcs/month |
| Delivery Time: | 10-20 days |
| Packaging Details: | Carton |
| Car make: | For Toyota RAV4 Corolla 2019 |
| Screen size: | 9 inch |
| Screen: | HD IPS Capacitive Touchscreen |
| System: | Android OS 4.4/6.0/7.1/8.1/9.0 |
| Ram: | 1GB/2GB/4GB |
| Rom: | 16/32/64GB |
| GPS / Glonass: | Support |
| Mirror-Link: | Support |
| OBD / TPMS: | Optional |
| FM|Am: | Support |
| RDS: | Support |
| Aux: | Support |
| Carplay: | Optional |
| Bluetooth: | Support Hands-Free Call&Music Streaming |
| Easyconnection: | Built-in |
| Android Auto: | Optional |
| Auto Reversing Camera Video: | Yes |
| Plug&Play: | Yes |
| WiFi: | Built in |
| DSP: | Optional |
| Built-in 4G SIM: | Optional |
| Warranty: | 12 Months |
| Osd language: | Multi-language supported |
| Dual zone function: | SUPPORT |
| Steering wheel control: | Support |
| DAB+: | Support but optional |
9 inch Toyota RAV4 2019 Android Autoradio GPS Navigation System with optional 4G SIM DSP CarPlay supports Steering Wheel Control Rearview Camera and built-in Bluetooth FM RDS Radio
General
Pin-to-Pin connectors and standard wiring harnesses for plug & play.
Support original Steering Wheel Control.
Support Dual Zone function.
Support external USB flash.
Operating System
Multiple Android OS options: Android 64-bit 6.0|7.1|8.1|9.0 OS.
Multiple hardware options: Quad-core|Octa-core CPU with 1GB|2GB|4GB RAM and 16GB|32GB|64GB ROM.
Multiple OSD language options: English, Russian, Arabic, German, Spanish, French, etc.
Display
9 inch capacitive multi-touch touch screen.
Support screen display turned off while the unit keeps running.
Multimedia
Support upto 4 x 45W Surround Stereo|Subwoofer output power and multiple EQ modes.
Built-in DSP(optional).
Support Aux in/out.
Navigation
Built-in GPS|Glonass.
Support multiple Android apps for navigation.
Radio
Built-in FM|AM Radio Tuner with RDS supported.
Support external DAB+ Tuner via USB.
Connectivity
Built-in WiFi and support Hotspot for internet sharing.
Support external 3G/4G dongle by USB or built-in 3G/4G SIM for internet access.
Built-in mirror-link or built-in Android Auto|Apple CarPlay(optional) for connecting with Android|IOS smartphone.
Built-in Bluetooth for hands-free calling and music streaming.
Optional features|parts
Rear View Camera | Digital TV Receiver | DVR | Bluetooth OBD | iPod
ready stereo | Apple CarPlay | Google Android Auto | USB DAB+ tuner
| 4G dongle, etc.
Android Specs
| General | |||
| Plug & Play | Yes | Dual Zone function | Support |
| Phone Link | Built in Mirror-Link| or built-in Apple CarPlay|Android Auto(optional) | Steering Wheel Control | Support |
| Optional Parts Supported | DAB+ Tuner| TPMS| DVR| OBD|OBDII| Digital TV Receiver (DVB-T|DVB-T2|ISDB-T|ATSC)| Rear Camera| Carplay|Android Auto| 3G|4G SIM| 3G|4G dongle| iPod ready stereo. | ||
| Operating System | |||
| Version | Android 64-bit OS 6.0|7.1|8.1|9.0 OS | Processor|CPU | Cortex-A7 Quad|Octa Core 1.6GHz| T3|T8|TS9 |
| Memory|RAM | 1GB|2GB|4GB DDR3 | Memory|ROM | 16GB|32GB|64GB EMMC |
| OSD Language Options | English| Russian| Arabic| German| Spanish| French| Thai| Italian| Vietnamese| Portuguese| etc. | ||
| Display | |||
| Screen Size | 9.0 inch | Screen type | TFT-LCD IPS Capacitive multi-touch screen |
| Resolution | 1024*600 | Camera Video In | Automatically switch to rear camera when reversing |
| Digital RGB Backlight | Support | Brightness Control | Support |
| Navigation | |||
| Built-in Navigation | Support GPS|A-GPS|Glonass|BDS | Supported Android APP for Navigation | TOMTOM| ROUTE66| IGO| NAVITEL| SYGIC| Yandex| Waze| etc. |
| Navigation Language | Depends on map software options | Maps Storage | Built in Flash or external SD card |
| Other | Music/Radio/Bluetooth…can still work when GPS navigation is working | ||
| Internet Access | |||
| WiFi | WLAN 802.11bgn| 2.4GHz | Hotspot | Support |
| 3G|4G | Support external 3G|4G dongle via USB. | ||
| Optional built-in 3G/4G SIM. | |||
| Bluetooth | |||
| Hands-free Phone Call | Support | Bluetooth Music Streaming | Support |
| Phonebook Downloading | Support | A2DP/Bluetooth OBD | Support |
| Multimedia | |||
| Audio Format Supported | MP3| WMA| AAC| RM| FLAC| etc. | iPod Ready Stereo | Optional |
| Photo Format Supported | JPG| BMP| JEPG| GIF| PNG| etc. | 1080P Video Playback | Support |
| Photo Format Supported | AVI| MKV| MOV| MP4| MPEG| MPG| RMVB| H.265| etc. | DSP | Optional |
| Radio | |||
| Radio Tuner | FM|AM | FM IC | NXP 6686 |
| RDS | Support | DAB+ | Support optional DAB+ receiver by USB |
| Radio Response Bandwidth | AM: 522~1620 KHz| FM: 87.5~108 MHz | Qty. of Preset FM|AM Stations | 36 Preset Radio Stations (FM: 3*6| AM: 3*6) |
| Media Format Supported | CD| HDCD| MP3| WMA| VCD| DVD| DVD-R|RW| DVD+R|RW| CD-R|RW| JPEG| etc. | ||
| Audio Stereo | |||
| Max. Audio Out Power | Channel Qty. | 45W*4 | Subwoofer | Support |
| Multiple EQ modes | Yes | Audio Out Channel | Audio 5.1 |
| Audio Signal-to-Noise Ratio | ≥85dB | Loudness Control | Yes |
| Mechanical | |||
| Form Factor | In-Dash | Audio Out | 4 Channels |
| Enclosure Type | 1 DIN | Subwoofer Out | 1 Channel |
| Video In | 3 Channels: 1 for DVR| 1 for Camera| 1 for Aux in | Antenna | 2 totally: 1 for GPS|1 for WiFi |
| Video Out | 1 Channel | USB | 2 Channels |
| Aux Audio In | 1 Channel | ||
| Electrical | |||
| Quick Boot & Shut | Yes | Rated Working Voltage | DC 12V |
| Max. Operating Current | 10A | Operating Voltage Range | 10.8V ~16V |
| Standby Current | ≤10mA | Shut Off Display | Support |
| Anti-Shock Design | Mechanical anti-shock & Electronic anti-shock | ||
| Environmental | |||
| Operating Temperature | -20°C to +70°C | Storage Temperature | -30°C to +80°C |
What Astral Electronics do?
1. OEM factory since 2009, working with car manufacturers for years.
2. Hundreds of OE-fit models available for different cars, and keep releasing new products regularly.
3. Support customization by developing special designs as request.
4. Quality guaranteed products.
5. CE/RoHs approved products, and other certificates available.
6. Multiple material sourcing channels to ensure stable supply and
on-time delivery.
7. Local technical support negotiable.
|
