PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft

Categories Fuel Level Sensor
Brand Name: Atech
Model Number: PL332
Certification: CE,RoHS
Place of Origin: China
MOQ: 1pc
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 pcs month
Delivery Time: 5-8work days
Packaging Details: standard export packing ,carton packing, water proof, shock resistance or according to customer's requirements.
Level range: 200mm ~ 1000mm (can be customized)
Output signal: RS232 (Voltage)
Operating temperatures: - 40 to 85°C
Rated current for switch: 500mA
Mounting: recommended 2 mm thick FPM gasket if be used in gas tank
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

PL332 GPS Digital Capacitance Level Sensor Anti Fuel Theft

PL332 Anti Fuel-Theft GPS Digital Capacitance Level Sensor

The PL332 sensor series uses capacitance as the sensitive element to continuously detect the oil level with a resolution of 1mm. The sensor length can also be shortened to accommodate tanks of different heights. With a wide range of voltage input and easily adjustable length, the PL332 is easy to set up and suitable for a wide range of applications.

Applications

1.Brass nickel-plated material is strong and durable Fix the cable to prevent disconnection

2.Reduce oil rod damage caused by the impact of oil tank shaking on the bumpy road section

3.Comes with 5 M5 screws and 2mm thick rubber NBR gasket Completely prevent gasoline penetration and corrosion Simple installation and convenient maintenance

4.Strong and oil-resistant, flame-retardantRed: positive powerBlack: negative powerBlue: output (0-5V, 0.5-4.5V, RS232, RS485)

Feature of water capacitive level sensor

1. Light weight and low cost

2. Length can be customized

3. Without limitation of environment

4. Long using life, wear resistance

Specifications

Material
Aluminum alloy
Length range
Installation
SAE standard 5 holes
Flanges
Various types of flanges are available for fitting fuel tank if necessary
Mounting

5 pieces of M5 screws and 2 mm thick NBR gasket,

or recommended 2 mm thick FPM gasket if be used in gas tank.

Supply voltages
10 to 32V
Rated current for switch
500mA
Output signal
0 to 5V (Voltage)
RS232
RS485
Operating temperatures
Protection rank IP65
Resolution 1mm

We have the 0-190ohm/240-33ohm , the length of sensor can customize, if you need other signal and length, if you need wholesale or dropping shipping, welcome to contact to us.we support all wholesale and drop shipping.
