140DDI35300 Low voltage dc discrete input module Modicon Quantum - 32 I 24 V DC

Range of productModicon Quantum automation platformProduct or component typeLow voltage dc discrete input modulesDiscrete input number32
ComplementaryGroup of channels4logic inputPositive (sink)Discrete input voltage24 V DCInput voltage limits19.2...30 VVoltage state 1 guaranteed15...30 V DCVoltage state 0 guaranteed-3...5 V DCCurrent state 1 guaranteed>= 2 mA at Us = 5.5 V and Uin = 0 VCurrent state 0 guaranteed<= 0.5 mAAddressing requirement2 input wordsInput impedance2500 OhmMaximum leakage current200 mA at Us = 5.5 V and Uin = 4 VAbsolute maximum input30 V continuous
56 V during 1.3 ms decaying pulseResponse time<= 1 ms from state 0 to state 1
<= 1 ms from state 1 to state 0Protection typeInput protection by resistor limitedPower dissipation1.7 W + (0.36 x number of points on)Isolation between group and bus1780 Vrms for 1 minuteIsolation between group500 Vrms for 1 minuteLocal signalling1 LED (green) for bus communication is present (Active)
1 LED (red) for external fault detected (F)
32 LEDs (green) for input statusMarkingCEBus current requirement330 mAModule formatStandardNet weight0.3 kg
EnvironmentStandardsCSA C22.2 No 142
UL 508Product certificationsC-Tick
DNV
RINA
RMRS
BV
GOST
ABSResistance to electrostatic discharge4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2Resistance to electromagnetic fields10 V/m 80…2000 MHz conforming to IEC 801-3Ambient air temperature for operation0…60 °CAmbient air temperature for storage-40…85 °CRelative humidity95 % without condensationOperating altitude<= 5000 m
Packing UnitsUnit Type of Package 1PCENumber of Units in Package 11Package 1 Height4.65 cmPackage 1 Width16.45 cmPackage 1 Length30.97 cmPackage 1 Weight409.2 gUnit Type of Package 2S03Number of Units in Package 27Package 2 Height30 cmPackage 2 Width30 cmPackage 2 Length40 cmPackage 2 Weight3494 gUnit Type of Package 3P12Number of Units in Package 3168Package 3 Height95 cmPackage 3 Width80 cmPackage 3 Length120 cmPackage 3 Weight92856 g
Contractual warrantyWarranty18 months
