| Categories | Prime Mover Truck |
|---|---|
| Brand Name: | CIVL |
| Model Number: | CIVL |
| Certification: | ISO,CCC |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | negociable |
| Supply Ability: | 1000 units per month |
| Delivery Time: | Within 35 days |
| Packaging Details: | nude with waxing on deck or in container |
| Driving mode: | 6x4 |
| Engine power: | 420 HP |
| Dimension: | 6980*2496*3850 mm (LWH) |
| Towing capacity: | minimum 40000KG |
| Pin size: | 60# /90# |
| Engine: | Euro II Euro III Euro IV |
Brand Description
Advantage of product
1. Powerful engine provide amazing towing power even whilst low rotation speed .
2. Axles and Tires mady with MAN`s techinque, excellent overloading capacity
3. 8+8 frame made by High strength alloy steel, key parts has been reinforced, it can fit very rough road.
4. Cabin adaopt BENZ techinque, confortable and safety for driver
Specifications
| Model | ZZ4257N3247N1B |
| Weight in kg | Curb weight :8800kg |
| Full rated:25000kg | |
| Towed mass:40000kg | |
| Dimension | Overall (mm) L*W*H 6985*2496*3210(2960;3500,3760,3980) |
| Wheel base:3200+1400mm | |
| Minimum ground clearance:280mm | |
| Performance | Max.speed: 90-102km/h |
| Economic speed: 72-89km/h | |
| Max.gradeability:25% | |
| Minimum turing circle:15m | |
| Engine | Model D1.34-31;D12.38-30 |
| MAX Output 420HP | |
| Max torque(Nm/RPM) 1490/1200-1500;1650/1100-1500 | |
| Transmission: | HW19715CL |
| Clutch | 430mm |
| Rear axle model | MCY13Q |
| Rear axle ratio | 4.11;3.7;3.36;3.08 |
| Fuel capacity | 400L |
| Overhang(Front sping/Rear spring) | 9/12;4/12;4/-;3/12;3/-;3/5 |
| Tyres | 315/80R22.5 |
| Frame section | 270x85x8mm |
| Driving mode | 6x4 |


|
