| PCB type: | 10 Layer Immersion Gold FR-4 Multilayer Circuit Board |
| Base Material: | S1000-2M |
| Number of Layers: | 10 Layer |
| Copper Thickness: | 1Oz. |
| Board Thickness: | 2.0mm+/-10% |
| Min. Hole Size: | 0.20mm |
| Min. Line Width: | 0.075mm |
| Min. Line Spacing: | 0.09mm |
| Surface Finishing: | immersion gold |
| Company Info. |
| Quanhong FASTPCB |
| View Contact Details |
| Product List |
10 Layer Immersion Gold FR-4 Multilayer Circuit Board
The 10 Layer Immersion Gold FR-4 Multilayer Circuit Board is a high-rise circuit board developed and produced by Shenzhen Quanhong Electronics Co., Ltd. this type of circuit board is made of shengyi S1000-2M material through mechanical drilling, surface gold deposition and other processes. The minimum aperture can reach 0.20mm and the minimum linewidth line spacing can reach 75 / 75um. It is mainly used in communication phase-shifting
Rigid PCB Manufacturing Capability
| PCB Manufacturing Capability | |
| Material | FR4,Arlon,Metal Core,Taconic,Nelco,Isola,Halogen Free,Rogers,PTFE,PI,ect |
| Max. Finishing Board Size | 1500X610 mm |
| Min. Board Thickness | 0.1mm for L<=2, 0.3mm for 4L&above |
| Max. Board Thickness | 10.0 mm |
| Buried / Blind Via (Non-cross) | 0.1mm |
| Aspect ration | 15:01 |
| Min. Drilling Size(Mechanical) | 0.15 mm |
| Tolerance PTH/ Pressing fit hole /NPTH | +/-0.0762 mm / +/-0.05mm / +/-0.05mm |
| Max. Layer Count | 40 |
| Max. copper (inner/outer) | 6OZ/12 OZ |
| Drill tolerance | +/-2mil |
| Layer to layer registration | +/-3mil |
| Min. line width/space | 2.5/2.5mil |
| BGA pitch | 8mil |
| Surface treatment | HASL, Lead free HASL, ENIG, Immersion silver/Tin, OSP |
| Having been contributed ourselves into PCB industry more than 10 years,Shenzhen Quanhong Electronics Co., Ltd has rich experience in fabricating FR4 PCBs, Flex/Flex-Rigid PCBs, Aluminum PCBs, Metal Core PCBs (MCPCBs), HDI PCBs, High-Frequency PCBs, High-Tg PCBs, Thick Copper PCBs and many other advanced PCB products. | |
| Detailed standard PCB capabilities of Shenzhen Quanhong Electronics Co., Ltd summarized into the following table: | |
| With 10+ years’ development, our PCB manufacture capabilities are more and more stronger, apart from standard PCBs and advanced PCBs, Shenzhen Quanhong Electronics Co., Ltd has the abilities to offer highly-mixed PCBs such as flexible PCBs laminated with FR4 for much higher application demands. | |
| Our PCB manufacturing capabilities include: | |
| a). Blind/Buried Vias or Microvias | |
| b). Via in Pad | |
| c). Countersink/Counterbore Hole | |
| d). Half-cut/Castellated Hole | |
| e). Gold Fingers | |
| f). Edge Plating | |
| g). Kapton Tape | |
| h). RoHS Compatibility | |
| Our products are widely applied in various area, such as Medical Care, Telecommunications, Consumer Electronics, Industry, Power, Lightening, Automotive, Aerospace, etc.. whatever what kind of PCBs you want, we will make it happen. | |
Packaging & Delivery | |||||
Packaging Details: | Inner: vacuum packing or Anti-static package, | ||||
Port: | Shenzhen or Hongkong | ||||
Lead Time: | Quantity(Pieces) | 1-10 | 11-100 | 101-1000 | >1000 |
Est. Time(days) | 3-5 | 3-5 | 7-9 | To be negotiated | |
