| Categories | Wireless Collaboration System |
|---|---|
| Brand Name: | Quickshare |
| Model Number: | QuickShare L2 |
| Certification: | CE RoHS CCC SRRC ISO9001 |
| Place of Origin: | Shenzhen China |
| MOQ: | 10Pcs or OEM/ODM/SDK Service |
| Price: | Negotiation |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 10K/Month |
| Delivery Time: | 3-8 working days |
| Packaging Details: | Gift box -210*180*90cm 500g,including Adaptor,Receiver box,Transmitter(can be 1/2/3 or 4pcs) |
| Resolution: | 4K@30hz /1080P |
| Support System: | Win7/Win8/Win10/MAC/Linux /Android/IOS |
| Feature: | Miracast/ Airplay/DLNA/WiDi/Chromecast |
| Model name: | Meeting Room Wireless Presentation System |
| Screens: | 2 Screens |
| Distance: | 66-164ft |
Wireless Collaboration System Transmitter Receiver Support iOS
Android Windows Mac System
Quickshare is a wireless presentation system for Meeting room &
School.
1,Support Miracast,Airplay,Windows,Mac mixed casting, All the
devices no need download the APP.
2, Support Miracast & Airplay simultaneously at the same screen.
3, Dual WiFi Module , while mirroring, while surfing on internet.
4, Support Dual screens
5, Support 5G hotspot &5G Sta
6, Can be 1pcs or 2pcs transmitters for casting to the big screen
ClickShare Wireless Collaboration System Quickshare L2
Specification:
| Windows Mirroring via software | ||||
| Installation | Keep PC and box at the same internet,No need installation | |||
| Support System | Windows 7/8/10 | |||
| Resolution | 1920*1200,1920*1080,1366*768,1360*768,1280*800,1280*720 1024*768 | |||
| Frame Rate | Audio&Video 18~30Frame | |||
| Delay time | 100~180ms | |||
| Display mode | Support extended screen | |||
| Touch Back Control | Support Mouse mode | |||
| Connection paths number | 128 | |||
| The most qty display screen | Dual Screens | |||
| Connecting Internet | 1. When box connect to RJ45,PC Wi-Fi or wired connection of Network
| |||
| Wireless USB Dongle | ||||
| Installation | No installation, no configuration | |||
| Connection | USB Device | |||
| Support system | Windows 7/8/10,Apple Mac | |||
| Resolution | 720P~1080P | |||
| Frame Rate | Audio&Video 18~30Frame | |||
| Delay time | 100~150ms | |||
| Transmit distance | No obstacle 20meter | |||
| Display mode | Support extend screen(Windows 7/8/10) | |||
| Connection number | 1~8(If above8pcs, need additional routers) | |||
| The most qty display screen | Dual screen | |||
| Wireless Speed | TX 300Mbps | |||
| Wireless Protocol | IEEE 802.11 a/g/n/ac | |||
| Channel | 5.8G, Multi channel Selection | |||
| Authentication Protocols | WPA2-PSK | |||
| Upgrading method | PC USB Upgrading the dongle | |||
| Phones Wiress Mirroring | ||||
| Dual Wi-Fi | 5GHotspot &5.8G Wi-Fi working at same time,While mirroring, the phone can go surfing. | |||
| iPhone | iOS8 above, AirPlay mirroring,support multi-screens | |||
| Android phone | No need APP for mirroring, support Miracast of different android phones | |||
| Scanning Screen | Android devices scan QR to download APP | |||
| Other Functions | ||||
| Automatic Playback | Playback 4K source video from U-disk | |||
| Video/Audio | ||||
| Video decoding | Support H.264,H.265,VP8,RV,WMV,AVS,H.263,MPEG4 | |||
| Decoding solution | 4K | |||
| Touch System | ||||
| Connector | USB HID | Mouse mode | Support | |
| Capacitive touch panel | Support | |||
| Operation System | ||||
| System version | Linux | |||
| CPU | RK3229 | HDMI output | 1 | |
| DDR | 256M | USB | 2 | |
| Flash Memory | 512M | RJ45 | 1 | |
| Soft AP | 802.11AC 5.8G | Wi-Fi | 5G | |
|
