Categories | Stick Welding Generator |
---|---|
Brand Name: | RAMS |
Model Number: | RNW120 |
Certification: | CE |
Place of Origin: | CHINA |
MOQ: | 100 units mixed model |
Payment Terms: | T/T, L/C |
Delivery Time: | 25 work days |
Packaging Details: | Carton/Pallet/Wooden case |
DC Welding Current: | 120A |
Auxiliary Output: | DC 2kw |
Duty Cycle at rated amps avalible: | 60% @120A |
Fuel Tank Capacity: | 3.6L |
Engine Model: | 170F |
Fuel Type: | Gasoline |
DC Welding Voltage: | 22-28V |
Company Info. |
CHONGQING RAMS ELECTRIC CO.,LTD. |
View Contact Details |
Product List |
RNW120 Petrol Welding Generators Medium Frequency Permanent Magnet
MOQ:24units mixed model
Description
• Dc power 2 kW and electric welding 3.2mm electrode are used at the same time, the circuit can prevent welding penetration of 1mm thin plate;
• 120A current control, light weight, convenient transportation, affordable, low maintenance cost, suitable for public consumption;
• Applicable fields: construction, installation, civil, decoration, factory maintenance, supporting equipment, rougher light steel structure, auxiliary installation of power station, roads, Bridges, etc. Outdoor construction site reinforcement welding, installation welding.
Unit Specification | RNW120 |
DC Welding Current | 120A |
DC Welding Voltage | 22-28V |
Duty Cycle at rated amps avalible | 60% @120A |
Welding Rod diameter | 2.5-3.2mm |
Fuel Tank Capacity | 3.6L |
Fuel type | gasoline |
Generator Specification | |
Axillary Output | DC 2kw |
Voltage | 120V/220V/240V |
Dimensions&Weights | |
ShippingN.W/G.W | 73.85Ibs/33.5kgs |
Carton size | 570*450*480mm |
22.4*17.72*18.9in | |
Q'ty 20"/40"/40"H | 200/412/515 |
Engine Specification | |
Engine Model | 170F |
Start Method | Recoil start |
Borex stroke mm | 70*58 |
Engine type | Gasoline Engine, Single Cylinder,4-Stroke,OHV,Air-Cooled |
![]() |
