| Categories | Optical Dissolved Oxygen Sensor |
|---|---|
| Brand Name: | Desun Uniwill |
| Model Number: | DS-380 |
| Place of Origin: | China |
| MOQ: | 0~100 pcs |
| Price: | $280.00 - $360.00/ Piece |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 0~1000 pcs |
| Delivery Time: | 7~ 15 working days |
| Packaging Details: | Carton packaging |
| Certification: | CE |
| Measuring range: | 0~20mg/L |
| Response time: | 3 seconds |
| Protection level: | IP68 |
| Power supply: | DC 6~12V |
| product material: | POM/SS316/Titanium |
| Power consumption: | < 0.5 W |
| Calibration method: | One or Two-point calibration |
| Accuracy: | 1% |
| Maximum working pressure: | 6bar |
| Fluorescent cap life: | 1 year |
| Item | Parameters |
| Model | DS380 |
| Principle | Fluorescence analysis method |
| Measuring range | 0~20mg/L or 0-200% saturation |
| Response time | 3 sec |
| Accuracy | 1% |
| Protection level | IP68 |
| Installation | Submersible |
| Temperature sensor | NTC |
| Temperature range | 0~50°C |
| Temperature accuracy | ±0.2°C |
| Output | Support RS-485, MODBUS protocol |
| Power supply | DC 6~12V, current <50mA |
| Size | Φ26*155 mm |
| Probe cable length | Default 5 m, customized 10m, 15 m and 30 m cable |
| Fluorescent cap life | 1 year |
| Maximum working pressure | 6bar |
| product material | POM/SS316/Titanium alloy |
| Calibration method | One or Two-point calibration |
| Power consumption | < 0.5 W |
Maintenance schedule
Unlike the electrochemically-dissolved oxygen probe technology, the fluori-dissolved oxygen probe does not consume oxygen and does not require frequent cleaning (except when applied to viscous liquids).
| Maintenance tasks | Recommended maintenance frequency |
| Cleaning sensor | Clean every 30 days |
| Check sensor and fluorescent cap for damage | Check every 30 days |
| Replace the fluorescent cap | Change once a year |
Calibrate the sensor (if required by the competent authority) | According to the maintenance schedule required by the competent authority |
Note:
The maintenance frequency in the above table is only a recommendation. Please maintain the sensor according to the actual usage of the sensor. However, the replacement of the fluorescent cap is recommended to be replaced once a year.
