120 Ton Forklift Tire Press Machine With Press Tooling Heavy duty

120 Ton Forklift Tire Press Machine With Press Tooling Heavy Duty

Introduction

Product Specification

• Heavy duty frame: The construction is welded by large-scale beam and channel beam.
• High-grade Hydraulic Cylinder: The biston rod is grinded and hard-chromium plated.
• Easy pull and press into the rims.
• Voltage and phase customized according to different power supply.

• Model	TP120
  Nominal pressure	1.2 MN​
  Work hydraulic	15 Mpa
  Max Tire Size	15 Inches
  Max Cylinder Stroke	600 mm
  Motor	4 KW
  Oil Tank Capacity	90 L
  Size	L2050xW650xH2200 mm
  Weight	1600 kg

Usage method of forklift tire press

First of all , choose a good tooling correctly, put the mould on the work table, and then put the wheel on the mould, handling pressure head to Press the die on the tire and finally with the boot ring loaded. Different types of tyres and wheels need different tooling, the user to install the tire before the selection of tooling, then the disassembly and assembly operations, it will be very convenient and quick. According to the motion mode and the size of the machine, the machine can be divided into manual press and electric press, which is generally suitable for large tonnage forklift truck or truck tire.

• NOTE:All parameters can be customized according to your esteemed customer's requirements!

•


•
