1hp 0.75kw Small Industrial Vibrators , Stable Frequency Vibration Motor Products

Categories Electric Motor Vibrator
Brand Name: DASION
Model Number: MV40/3
Certification: CE&ISO
Place of Origin: Henan Province, China
MOQ: 25 set
Price: EXW USD 37.5-126.5 per set
Payment Terms: T/T, Western Union, L/C
Supply Ability: 1000 sets per month
Delivery Time: 5-8 working days
Packaging Details: Wooden cases for electrical motor vibrators
Product name: 1hp 0.75kw mini portable small electric motor vibrator for vibrating table
Force: 0.3KN
Power: 0.05kw
Weight: 4kg
Installation size: 62-74, 106
Color: Red or your required
Material: Aluminum shell
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

1hp 0.75kw Small Industrial Vibrators , Stable Frequency Vibration Motor Products

China manufacturer small portable industrial electric motor vibrator for concrete

Product Description

Electric vibrating motor is a excitation source that the combination of the power source and the vibration source,which is the greatest excitation source of linear vibrating screen,vibrating feeder,vibrating hopper,vibrating conveyor and such vibration equipment.Its exciting force can be adjusted with stepless.and it is ideal equipment of metallurgy,mining,building material,coal,grain,Abrasive materials,chemical industry etc,and it can be used for Silo vibration of bin,hopper,chute,to avoid material stay and to make material fast move.It has a wide ranges of applications.

Precautions

Precations in installment and adjustment:

1. Before and after adjusting the vibrating force, it is necessary to secure the adjusting screw in order to prevent the vibrating vanes from jumping out.
2. Constantly check the screw on foot and the outlet cord for sure security and normal operation.
3. In selection of motor base, the tensile strength of the base should be taken into consideration so that the mechanism may not be damaged.
4. Under the normal usage, the maintenance practice should be conducted once every 3000 hours of running.

Product Parameters

No.ModelForce(KN)Power(KW)Weight(KG)Installation Size
AB
1MV40/30.30.05462-74106
2MV60/30.70.074.262-74106
3MV100/310.094.662-74106
4MV200/320.156.862-74106
5MV300/330.259.890125
6MV400/340.2710.390125
7MV500/350.515.8105140
8MV700/370.5916.5105140
9MV800/380.720.6120170
10MV1200/3100.9521.6120170
11MV1300/3131.324.5120170
12MV1600/3161.5451.6140190
13MV1800/3181.8552140190
14MV2000/3202.151.8140190
15MV2200/3222.452.8140190
16MV2300/3232.453.6140190
17MV3200/3322.7696.9155255
18MV4000/3402.9107155255
19MV5000/3504112155255
52MV60/3M0.70.084.562-74106
53MV100/3M10.15.162-74106
54MV200/3M20.136.862-74106
55MV50DC-240.50.14.562-74106
56MV200DC-2420.166.562-74106

How To Confim The Model

1. If you have ever used the motor,please give me the model number directly.

2. If you have not used the motor,Please confirm the questions as below:Power,Exciting force,Number of poles,The size of installation.how many sets.Voltages and hertz.
