Screw Thread Installation Precision Pressure Sensor RS485 Digital Output Pressure Sensor

Pressure Transducer

Feature

• Accuracy: ±0.5%F.S,±1%F.S
• Diffused silicon oil-filled core

Or ceramic piezoresistance core, optional

• Multiple pressure range
• Screw thread installation
• RS485 Digital output

Application

• Hydrologic monitoring
• Constant pressure water supply
• Frequency conversion water supply
• Sewage treatment
• Water-saving irrigation
• Hydroelectric power
• Diversion works

Introduction:

The characteristics of the GXPS602 pressure transmitter are with high reliability, high stability, and digital output. Widely used in gas, liquid pressure testing, such as water, oil, mildly corrosive liquids and gases. This series of products has 1Cr18Ni9Ti stainless steel structure, RS485 output.

GXPS 600A: 3.6Vdc battery-powered, low-power products

GXPS 600C: 3.6Vdc battery-powered, low-power and low accuracy products

Electronic interface and signals definition

Hurischmann fitting:

1——power

2——power ground

3——RS485+

——RS485-

Parameters
