AUTODP Suction Up To 50M Submersible Deep Well Water Pump For Underground Pumping

Categories Automatic Water Pump
Brand Name: ZOZHI
Model Number: AUTODP-505-1
Certification: CE/SGS/ISO
Place of Origin: CHINA
MOQ: 1pc
Price: negotiated
Payment Terms: T/T, L/C
Supply Ability: 30000pcs/month
Delivery Time: 25 working days after received your payment
Packaging Details: Packed in cartons , overall size:525x250x300mm/pc, N.W.: 31gs
Product Name: Automatic Water Pump
Application: boosting
Power: 1.5HP / 1.1KW
Flow Max: 95L/Min
Head Max: 42m
Suction Max: 25m
Insulation: Class B
Tank capacity: 18L
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

AUTODP Suction Up To 50M Submersible Deep Well Water Pump For Underground Pumping


AUTODP Suction Up To 50M Submersible Deep Well Water Pump For Underground Pumping


Automatic Water Pump ADVANTAGES:


a) The problem of start and stop frequently disappeared, protect the pump, and extend life.

b) Italian quality motor

c) Good quality bearing, the surface more smooth, the dimension more precise

d) The special spray-paint technique, beautiful and more stable

e) One year warranty


AUTOMATIC WATER PUMP APPLICATIONS:


  1. Auto series of a pump is constituted with clean water pump, non-return valve, and air-water separation room, which located on the upside of the pump body.
  2. During operating, it is no need to use a foot valve, the only thing that you should do is just leave some water in the pump body.
  3. After a few minutes of running, the water will be sucked out relying on the pump body itself.
  4. They are particularly suitable for domestic applications such as supplying water from a well, pool, etc.
  5. It is also suitable for water pressure boosting, gardening, and automatic water supplying if combined with other appliances.

STRUCTURAL CHARACTERISTICS:


Main SpecificationStandardOptional
Transmission mediumClean Water
Pump bodyCast Iron
ImpellerBrass
Motor housingAluminum
Stator&Rotor1. Cold-rolled silicon steel sheet by high-speed punching machine. 2. 100% high-quality copper wire
Front coverCast Iron
BearingChinese Best Quality BearingNSK, SKF, or on request
Mechanical sealGraphene/CeramicSilicon Carbon
ShaftCarbon SteelStainless Steel
InsulationClass BClass F
ProtectionIP44IP54
Voltage220-240V Single PhaseOn Request
Frequency50HZ60HZ
Thermal protectionNoYes
Automatic Pressure Control SystemNoYes
Cooling TypeExternal Ventilation
Max. Suction lift9M
Max. Fluid Temperature+60℃
Max. Environment Temperature+40℃
InstallationHorizontal
Connect TypeThread
CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC

Automatic Water Pump TECHNICAL DATA:


ModelOutputSuct.MaxR.P.M.Q.MaxH.MaxSuct.Max.Pipe DiaLxWxHN.W.
HP / KW(m)(l/min)(m)(M)(mm)(Kg)
DP-550A0.75 / 0.551528504035151"x1"490x210x23016.5
DP-750A1 / 0.752028504840201"x1"490x210x23017
DP-5051.5 / 1.12528509542251"x1"525x250x30031

Other voltages and frequencies available on request


INSTALLATION SIZE


auto JET self-priming pump


GUARANTEE


Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.


OUR SERVICE


1). We are very glad that the customer gives us some suggestions for price and products.
2). Any questions, please let us know it in the first by E-mail or Telephone. We can deal with them for you in time.
3). Offer our customers the lowest prices. Streamline the buying and paying processes.
4). Deliver goods to our customers all over the world with speed and precision.
5). Ensure the excellent quality of our products.
6). 12 months FREE warranty.
7). Accept OEM



FAQ:

1). Q: How about the MOQ?
A: Usually, it is 50 PCS for each model.

2). Q: Are you a factory or a trading company?
A: we make water pumps, motors, alternators, and diesel generators since 2006.

3). Q: Can you accept to use our logo?
A: Yes, we can. Any OEMs are welcome!

4). Q: What are your payment terms?
A: 30% deposit by T/T in advance, pay 70% balance against B/L copy.

5). Q: How about the delivery time?
A: Usually, 10-30days. But it depends on your order quantity.

6). Q: How about the warranty?
A: 1 year from shipped on board date.
