| Categories | Handheld Barcode Scanner |
|---|---|
| Brand Name: | DY SCAN |
| Model Number: | DS6520B-2D |
| Certification: | CE, ROHS, FCC, IEC |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negotiate |
| Payment Terms: | T/T, Paypal, Alibaba |
| Supply Ability: | 100000pcs/month |
| Delivery Time: | 3-7 days |
| Interface Type: | Wireless 2.4G and bluetooth |
| Depth of field: | 30-600mm |
| Resolution: | ≥3mil/0.1mm（PCS90%,CODE 39） |
| Speed: | 65cm/ |
| Scan mode: | Manual ,Auto Sense, continuous |
| Scan angle: | Roll±360°, Pitch±60°, Skew±55° |
| Battery capacity: | 2200MAH |
| Print Contrast Signal: | 15% |
| Size: | 175*55*86mm Scanner 130*100*100mm Stand |
| Company Info. |
| Shenzhen DYscan Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Features
☆ Ergonomic design, comfortable using.
☆ Read all mainstream 1D 2D barcodes in the market easily.
☆ Interface: USB, bluetooth 4.2,Wireless 2.4G.
☆ Ultra-low power consumption.
☆ Bluetooth , long wireless distance 30m(2.4G ,150M), can be used in mobile phone and PC.
☆ Widely used in supermarket, warehouse, mobile payment, chain stores.
Parameter
| Light Source | Red Light LED 525±10nm(aim), 5600K LED ( Lighting) Note: global exposure camera, lighting brightness will change automatically according to different reading distance. |
| CPU | 32-bit |
| Resolution | 640*480 |
| Resolution | ≥3mil/0.1mm(PCS90%,CODE 39) |
| Decoding speed | 65CM/S |
| Depth of field | 30mm~600mm |
| Scan Mode | Manual , Auto Sense, Continuous |
| Scan view | 41° * 31° |
| Scan angle | Test Conditions:CODE39,10mil/0.25mm,PCS90% |
| Roll±360°, Pitch±60°, Skew±55° | |
| Print Contrast Signal | ≥15% |
| Ambient Light | Dark environment, indoor natural light |
| Wireless communication mode | Synchronization , storage |
| Wireless transmission distance | 2.4GHz,100m, Bluetooth,30m (Open distance) |
| Storage | 350Kb(over 20,000 Product code) |
| Battery capacity | 2200mAh |
| Battery charging time | 6.5 h |
| Continuous working time | ≥20h |
| Symbologies | 1D:UPC-A,UPC-E,EAN-8,EAN-13,Code 128, GS1-128, Code 39,Code 32, Code 93,Code 11,Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5(Straight 2 of 5),Standard 2 of 5(IATA 2 of 5),Codabar(NW-7),MSI,GS1 Databar(Omnidirectional, Limited, Expanded),China Post, Tepepen, Febraban (Brazil bank code),GS1 Composite, Japan post, etc. 2D: QR Code, Micro QR Code, Data Matrix,PDF417, Micro PDF 417, MaxiCode, Aztec,HanXin Code, etc. |
| Weight | ≈160g(without cable) |
| Dimension | 60*80*165mm Scanner |
| 95*120*98mm Stand | |
| Communication Mode | USB,Wireless 2.4G,Wireless Bluetooth 4.2 |
| Interface Type | USB |
Q:Can i make a trial or sample order before ordering?
A: Yes,sure
Q: How can i print my logo on scanner? how much ?
A: Firstly,pls inform us your logo and printing position
expected,then we will make sample for your confirmation shortly The
cost depends on some factors.
Q:Can we have our logo or company name to be printed on the product
or package?
A:Yes, printer with logo or company name is acceptable, it will be
accomplished by silk printing, please contact us for more details.
Q: How about your warranty?
A: The buyer will enjoy 1 year warranty since buying from us
Q: If the scanner not working ,how can we do ?
A: pls contact and inform related sales representative with the
issues you have
|
