Cisco 4000 Series ISR Modules & Cards NIM-2FXO= 2-Port Network Interface Module

Categories Optical Transceiver Module
Brand Name: Cisco
Model Number: NIM-2FXO=
Certification: CE
Place of Origin: China
MOQ: 1 piece
Price: Negotiable
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000 pcs / month
Delivery Time: 1-2 days
Packaging Details: New in box
Brand: Cisco
Model: NIM-2FXO=
Device Type: Voice / fax module
Form Factor: Internal
Connectivity Technology: Wired
Analog Ports Qty: 2
Interfaces: 2 x FXO
Designed For: Cisco ISR 4331, 4351
Warranty: 1 year replacement warranty
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Cisco 4000 Series ISR Modules & Cards NIM-2FXO= 2-Port Network Interface Module

NIM-2FXO= Overview


The NIM-2FXO= is a Network Interface Module (NIM) designed for Cisco routers, specifically providing two Foreign Exchange Office (FXO) ports. Here are some key features and specifications:

Key Features

  • Ports: Provides two FXO ports, allowing the router to connect to traditional PSTN (Public Switched Telephone Network) lines.
  • Functionality: Enables voice and fax communication over analog lines, facilitating connectivity for legacy systems.
  • Compatibility: Compatible with various Cisco routers that support NIM modules, enhancing the router's capabilities.
  • Modularity: Allows for flexible configuration and expansion of voice services within the network.

Use Cases

  • Voice Gateway: Acts as a gateway for connecting VoIP (Voice over IP) systems to traditional phone lines.
  • Branch Office Connectivity: Useful in branch offices that require connectivity to the PSTN while using VoIP internally.
  • Backup Connectivity: Serves as a backup connection for voice services in case of VoIP service failure.

2-port Network Interface Module - FXO (Universal)


NIM-2FXO= Specification


NIM-2FXO= Specification

General
Device TypeVoice / fax module
Form FactorInternal
Modem
Connectivity TechnologyWired
Analog Ports Qty2
Expansion / Connectivity
Interfaces2 x FXO
Compatibility Information
Designed ForCisco ISR 4331, 4351

NIM-4MFT-T1/E1= Specification

Number of Ports4
Clear-Channel DataYes
MFT Packet VoiceYes
Unstructured E1 (G.703) SupportNo
Channelized DataNo
Configuration DescriptionMFT Modules
Data Only
Serial data (channel-group*)2 per port
E1 unframed G.703Not Supported
Voice Only
Voice channel associated signaling (CAS) (ds0-group**)

24 per port (T1)

31 per port (E1)

1 per timeslot

Voice and Data
PRI (pri-group***)1 per port

Drop and insert

(tdm-group****)

24 per port (T1)

31 per port (E1)

1 per timeslot

Dimensions (H x W x D)1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)
Environmental

● Operating temperature: 0 to 50°C (32 to 122°F)

● Storage temperature: -20 to +65°C (-4 to 148°F)

● Relative humidity: 10 to 85% noncondensing operating; 5 to 95% noncondensing, nonoperating

T1 Compliance (partial list)

● TIA-968-A

● CS-03

● Jate

● ANSI T1.403

E1 Compliance (partial list)

● TBR4, TBR12, and TBR13

● ITU-T G.703, G.704, G.823, and I.431

● S016 (Australia)

Weight0.44 lb (200g)


Supported Platforms


ModelDescription
Cisco ISR4431/K9500Mbps-1Gbps system throughtput, 4 WAN/LAN ports, 4 SFP ports, multi-Core CPU, Dual-power, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC, separate control data and services CPUs
Cisco ISR4351/K9200Mbps-400Mbps system throughtput, 2 WAN/LAN ports, 3 SFP ports, multi-Core CPU,2 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC
Cisco ISR4331/K9Cisco 4000 Router, 100Mbps-300Mbps system throughtput, 2 WAN/LAN ports, 2 SFP ports, multi-Core CPU,1 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC

Compare to Similar Items


Part NumberNumber of PortsClear-Channel DataMFT Packet VoiceUnstructured E1 (G.703) SupportChannelized Data
NIM-1MFT-T1/E1 (=)1YesYesNoNo
NIM-2MFT-T1/E1 (=)2YesYesNoNo
NIM-4MFT-T1/E1 (=)4YesYesNoNo
NIM-8MFT-T1/E1 (=)8YesYesNoNo
NIM-1CE1T1-PRI (=)1YesYesYesYes
NIM-2CE1T1-PRI (=)2YesYesYesYes
