| Categories | Environmental Test Chamber |
|---|---|
| Brand Name: | DAXIAN |
| Model Number: | DX8495 |
| Certification: | ASRM G155-2013, ANSI Z97.1-2009, ASTM D2565 |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Standard export wooden case |
| Delivery Time: | 10 days after order confirmed |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash |
| Supply Ability: | 30 sets per month |
| Supply power: | AC380V, 10KW |
| Materails: | Stainless Steel SUS304# |
| Use environmental: | 5C~+30C, 85%R.H |
| Dimentions: | L*W*H 1650×1640×2420mm |
| Weight: | 800 kg |
| Communication: | RS232 |
| Company Info. |
| DONGGUAN DAXIAN INSTRUMENT EQUIPMENT CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
ASRM G155-2013 PID Temperature Control Xenon ARC Aging Test Chamber , Environmental Testing Chamber ANSI Z97.1-2009
Descriptions:
PID Enviroment Ac380v , Three Phase Five Wire , 10kw Xenon Arc Aging Test Chamber is used for the examination of the ultraviolet irradiation resistance capacity when the materials/products are exposed in ultraviolet irradiation environment. Ultraviolet light is a term used to describe electromagnetic radiation with ultraviolet waves shorter than light visible to humans.UV light is present in sunlight and can cause chemical reactions in certain materials. This reaction caused them to glow,which is called fluoresce. It is widely applied to coating ink, paint, resin, plastics, printing, packaging, aluminum profile,cement, automobile, motorcycle, cosmetics, metal, electronic, electroplating, medicine, etc.
Standards:
ASRM G155-2013, ANSI Z97.1-2009, ASTM D2565.
Feature:
(1) Condensation device simulates the effect of humidity of outdoor, meeting 100% humidity.
(2) Electronic-eye irradiance control system.
(3) Use blackboard temperature sensor providing precise temperature and recurring test result.
(4) Perform humidifying, condensation and water spraying circulating test.
(5) Irradiance is calibrated by CR-10 calibrator and automatic calibration procedure (Paten technology)
(6) Specimen size and quantity: 75mm×300mm 24pcs, 75mm×150mm 40pcs.
Technical parameters:
| Inner Box Size (DWH) | 950×950×900mm |
| Outside Dimension (DWH) | 1300×1500×1900mm |
| Humiture Range | (RT±10)~70C; 30~98%RH |
| Humiture uniformity | 2C; 3%RH |
| Rainfall time | 1~9999min, adjustable |
| Rainfall cycle | 1~240min, interval is adjustable |
| Xenon lamp light | xenon long-arc lamp, 6KW10%, 290-800nm, 1000W/m2200 |
| Heating/humidifying power | 2.0KW/2.0KW |
| Sample spinning machine speed | 1~5r/ min (adjustable) |
| Sample and xenon lamp distance | 300~375mm |
| Box material | Stainless Steel SUS304# |
| Insulation materials | Superfine heat insulation cotton |
| Insulation body | Superfine glass fabric |
| Circulation system | Single cycle, centrifugal fan |
| Control system | Germany KLOCKNER-MOELLER progammable controler |
| Gas processing | dischager for fector and harmful gas |
|
