Electric Infrared Heated Floor Thermostat , Underfloor Heating Programmable Thermostat

Electric Infrared Heated Floor Thermostat , Underfloor Heating Programmable Thermostat

Heated Floor thermostat with LCD screen, which has manual mode and energy saving mode. The thermostat is recommended for the control of electric heating device or on/off valve actuator in hydronic underfloor heating.

Technical data

Voltage: 220V-240V

Power Consumption: 2W

Setting Range: 5-35℃(Can adjust to 5-90℃)

External limitation: 5...60℃(Factory setting: 35℃)

Sensor:NTC internal/external sensor

Switch differential: 0.5-10 ℃adjustable (Factory setting: ±1℃)

Ambient temperature:-5-50℃

Protection housing: IP20

Housing material: Anti-flammable PC

Selection Table

Sensor Failure

E0:Built-in sensor short-circuited or disconnected

E1:Exernal sensor short-circuited or disconnected.

When shows E0/E1 error, thermostat must be checked till the error is eliminated.

Package

Individual white box and outer carton, 64pcs in one carton.

Wiring Diagram
