Jo1 REV Redundant Power Supply Module HONEYWELL Digital Output Card TC-ODJ161

Redundant Power Supply Module HONEYWELL digital output card TC-ODJ161

Control Strategy Building

Experion PKS control strategies are built using Control Builder, a graphical, object-oriented tool that supports the Control Execution Environments of the Experion PKS Control Processor, Application Control Environment and Simulation Control Environment. It allows system design, documentation, and monitoring. It provides comprehensive handling of various I/O points, including Fieldbus, Profibus, and DeviceNet. In addition, it covers continuous, logic, motor, sequential, batch and advanced control functions through a library of Function Blocks (FBs).

QUICK DETAILS

1. Brand :Honeywell
2. Model : TC-ODJ161
3. Place of Origin : USA

DESCRIPTION

• digital output card
• Output Module

• Brand :Honeywell
• Model:honeywell digital output card TC-ODJ161
• Quality:Original
• Use: DCS
• Custom processing: Yes
• Application:Petrochemical and other fields
• Professional to provide a Honeywell DCS card, integrity services, absolute guarantee is part of the original Honeywell new card, the scope of services involved S9000, plantscape, TDC2000 TDC3000 (US operation station), TPS (Gus operation station), PKS and Honeywell DCS distributed control system

Function Blocks are basic block types provided by Honeywell to perform different control functions. Each block supports parameters that provide an external view of what the block is doing. FBs easily interconnect via “soft wires” to construct control applications or strategies. Function Blocks are grouped together and contained in Control Modules (CMs) and, in the case of sequential FBs, Sequential Control Modules (SCMs). SCMs greatly simplify batch logic implementation by sequencing a group of process equipment through a series of distinct steps to accomplish one or more process tasks. CMs and SCMs act as “containers” for Function Blocks. This is a very powerful tool for creating, organizing, and checking out control strategies. Figure 3 illustrates a simple Control Module -- in this case a PID loop -- consisting of basic FBs. In this example, several FBs are “contained” within the CM named FIC101, and the AI and AO FBs are executing in FOUNDATION Fieldbus devices. Each Control Module may be scheduled at its own execution rate from 5 msec to 20 sec (depending on the controller), and the user can schedule Function Blocks and Control Modules to execute in any desired order.

Similar Products

TC-OAH061 Analog Ouput 6pt Mod (4-20MA) CIOM-A
TC-OAV061 Analog Output Module 6 pt (10V), CIOM-A
TC-OAV081 AO Module 8pt (4-20ma & 10V), CIOM-A
TC-ODA161 AC Output Module 120/220vac 16pt, CIOM-A
TC-ODD321 DC Output Module 24vdc 32 pt, CIOM-A
TC-ODJ161 DC Output Module 24vdc 16pt, CIOM-A
TC-ODK161 AC Output Module 120/220vac 16pt, CIOM-A
TC-PCIC01 ControlNet Interface Card (PCI Bus)
TC-PCIC02 ControlNet Interface Module, PCI bus
TC-RPCXX1 120/240 VAC Redundant Power Supply
TC-TBCH Field Wiring Connector 36 pos
TC-TBNH Field Wiring Connector 20 pos
TK-CCR014 CNI, Redundant Media, Coated (TK-CCR013)
TK-FPDXX2 Conformal coated 24VDC Pwr Supply
TK-FXX132 13 slot chassis, coated, 13 amp
TK-IAH161 AI 16 Module, CIOM-A, Coated
TK-IDD321 DC Input 24vdc 32pt, CIOM-A, Coated
TK-IXL061 Thermocouple Input 6pt, CIOM-A, Coated
TK-IXR061 RTD Input 6pt, Coated
TK-OAV081 Analog Output 8pt, CIOM-A, Coated
TK-ODD321 DC Output 24vdc 32 pt, Coated
TP-DIKBTA-100 IKB Keyboard w/Trackball, Desktop
TP-DOKBNA-100 OEP KYBD DESKSIDE GUS
TP-LCNECM-100 XLCN EXTENDER SET CE MULTIMODE
TP-LCNP02-100 LCNP4M Interface Card, Mid-siz
TP-OPADP1-200 OEP Adapter, 240V, Deskside IKB
TP-OPADP1-201 OEP ADAPTER FOR DESK, WKS2, 24
TP-ZSBHM2-100 UPG KIT, HM TO SBHM W/TWO DRIVES
