Fixed Helium He Gas Detector Single Gas Detector With 4~20ma And
RS485 Signal Output
Application area are widely used in military, scientific research,
petrochemical, refrigeration, medical, semiconductor, pipeline leak
detection, superconducting experiments, metal manufacturing, deep
sea diving, High-precision welding, production of optoelectronic
products, etc. Our gas detector can used in different environment.
Specification
| Gas detected | Helium He | ||
| Detection principle | Thermal Conductance | ||
| Install method | Wall-mounted, piping type, flow-type (according to the detected environment) | ||
| Measure range | 0-100%VOL | ||
| Resolution | 0.01%VOL | ||
| Precision | ≤± 2% FS | ||
| Signal output | 4-20mA, 0-5V, RS485, relay(optional) | ||
| Response time | ≤10S | Recovery time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%(FS/year) | Display | High-light nixie tube display |
| Connection mode | G1/2 external thread explosion-proof flexible pipe | Unit | ppm |
| Temperature | -20 to 50°C | Humidity | 0-95%RH |
| Explosion-proof | Ex dⅡCT6 | Degree of protection | IP65 |
| Alarm | Sound, light | Operating time | 24H |
| Dimensions | 180*150*90mm | Weight | ≤2kg |
Characteristics:
1. Standard equipped with three-wire system 4-20mA analog output;
relay output; RS485 output.
2. Unique infrared ray control function, which can non-contacted
control the device.
3. Being compatible with all kinds of controlled alarms, PLC, DCS
and other control system, can be remote monitored.
4. Explosion-proof design, fast, reliable and stable.
5. Explosion-proof grade: Ex dⅡCT6
6. With self-calibration function, and three standard keys will be
used to realize on-site maintenance.
7. Detachable probe/gas cell: It is very easy to calibrate and replace sensor
Funtions:
1. Monitor the Helium He gas in environment or pipeline.
2. With self-calibration and zero calibration function, makes the
detection more accurate and reliable.
3. With temperature compensation, this is able to realize gas
concentration compensation under conditions of different
temperatures.
4. Infrared ray controller can remote control alarm point settings,
zero calibration, and address modification. (optional)
5. Can output one or two on-off signals, can drive ventilator or
solenoid valve and other external devices. (optional)
6. Working Voltage:24V DC
7. Case: die-cast aluminum
FAQ
Q: Does your company accept customization?
A: We do customizing service for customers. OEM/ ODM is welcome.
Q: Are you trading company or manufacturer?
A: Yuante Instrument is an ISO9001-2015 approved manufacturer with
around 10 years experiences.
Q: What’s the MOQ?
A: 1 pc is availble for customers to test our quality and services.
Q: How long is Yuante's lead time?
A: It depends on your purchasing quantity, it's 2~3 workdays after
payment generally.
Q: What about the Shipment?
A: We’ll choose proper transportation mode based on the weight of
goods, usually arrange shipment byair express such as DHL,FEDEX,TNT
or UPS.
Q: What about after-sale service?
A: 12 months warranty for all kinds of products;
|   |
